Products
MS Beams
Product Specifications
Minimum Order Quantity: 30Ton
Material Specification: Material will be supplied as per IS 2062:2008 Standard
| Designation | Wt/m(Kg) | Depth of Section(mm) | Width of flange(mm) |
|---|---|---|---|
|
MB-150
|
15 | 150 | 75 |
| MB-200 | 24.2 | 200 | 100 |
| MB-250 | 37.3 | 250 | 125 |
| MB-300 | 46 | 300 | 140 |
| MB-400 | 61.5 | 400 | 140 |
| MB-450 | 72.4 | 450 | 150 |
| MB-500 | 86.9 | 500 | 180 |
| MB-600 | 123 | 600 | 210 |
| HB-150 | 27.1 | 150 | 150 |
MS Channels
Product Specifications
Minimum Order Quantity: 30Ton
Material Specification: Material will be supplied as per IS 2062:2008 Standard
| Designation | Wt/m(Kg) | Depth of Section(mm) | Width of flange(mm) |
|---|---|---|---|
|
MB-150
|
16.8 | 150 | 75 |
| MB-200 | 22.3 | 200 | 75 |
| MB-250 | 30.6 | 250 | 80 |
| MB-300 | 36.3 | 300 | 90 |
| MB-400 | 50.1 | 400 | 100 |
MS Angles
Product Specifications
Minimum Order Quantity: 30Ton
Material Specification: Material will be supplied as per IS 2062:2008 Standard
| Size(mm) | ISA 110X110 | ISA 120X120 | ISA 130X130 | ISA 150X150 | ISA 200X200 |
|---|---|---|---|---|---|
|
8
|
13.4 | 14.7 | 15.6 | ||
| 10 | 16.6 | 18.2 | 19.7 | 22.9 | |
| 12 | 19.7 | 21.6 | 23.5 | 27.3 | 36.9 |
| 15 | 26.6 | 33.8 | |||
| 16 | 25.7 | 30.7 | 35.8 | 48.5 | |
| 18 | 40.1 | ||||
| 20 | 44.1 | 60 | |||
| 25 | 73.9 |
Unequal Leg Angles
| Size(mm) | ISA 110X110 | ISA 120X120 | ISA 130X130 | ISA 150X150 | ISA 200X200 |
|---|---|---|---|---|---|
|
8
|
13.4 | 14.7 | 15.6 | ||
| 10 | 16.6 | 18.2 | 19.7 | 22.9 | |
| 12 | 19.7 | 21.6 | 23.5 | 27.3 | 36.9 |
| 15 | 26.6 | 33.8 | |||
| 16 | 25.7 | 30.7 | 35.8 | 48.5 | |
| 18 | 40.1 | ||||
| 20 | 44.1 | 60 | |||
| 25 | 73.9 |
Unequal Leg Angles
MS Rounds
Product Specifications
Minimum Order Quantity: 30Ton
Material Specification: Material will be supplied as per IS 2062:2008 Standard
| Round Dia | Wt/m(Kg) | Round Dia | Wt/m(Kg) |
|---|---|---|---|
|
80
|
39.5 | 130 | 104.3 |
| 85 | 44.6 | 140 | 121 |
| 90 | 49.9 | 150 | 138.8 |
| 95 | 55.7 | 160 | 158 |
| 100 | 61.7 | 170 | 178 |
| 110 | 74.6 | 180 | 200 |
| 116.5 | 83.77 | 190 | 222.8 |
| 120 | 88.8 | 200 | 247 |
| 125 | 96.4 | 210 | 272 |
MS Flats
Product Specifications
Minimum Order Quantity: 30Ton
Material Specification: Material will be supplied as per IS 2062:2008 Standard
| Width(mm) | 100 | 120 | 130 | 140 | 150 | 160 | 180 | 200 |
|---|---|---|---|---|---|---|---|---|
|
10
|
15.7 | |||||||
| 12 | 15.1 | 17.0 | 18.8 | |||||
| 15 | 15.3 | 16.5 | 17.7 | 18.8 | 21.2 | 23.6 | ||
| 20 | 15.7 | 18.8 | 20.4 | 22.0 | 23.6 | 25.1 | 28.3 | 31.4 |
| 25 | 19.6 | 23.6 | 25.6 | 27.5 | 29.4 | 31.4 | 35.3 | 39.2 |
| 30 | 23.6 | 28.3 | 30.6 | 33.0 | 35.3 | 37.7 | 42.4 | 47.1 |
| 40 | 31.4 | 37.7 | 40.8 | 44.0 | 47.1 | 50.2 | 56.5 | 62.8 |
| 50 | 39.2 | 47.1 | 51.2 | 55.0 | 58.9 |
